MM 100/105
MM 100/105 SQUARE WITH BACK SHUTTER T-HCS
€39.70
This category includes our fans with ultra-thin nozzles. This unique technical solution became possible due to the patented ultra-thin engine with outstanding characteristics. The minimal thickness of the nozzle allows the installation of the fan in places with close to no installation space like inside of hanging ceilings or camper vans. The levels of protection of in-built electric engine allow the fan to work normally under the conditions of high humidity. All household exhaust fans are equipped with a net preventing insects from entering the room. They can also be customized with additional options: check valve, timer, humidity and light sensors, as well as in-built LED lighting
Specifications
PHASE / VOLTAGE, V | 1f / 230V |
CURRENT FREQUENCY, HZ | 50 |
POWER MAX, W | 17 |
PRESSURE, MAX, PA | 55 |
PRODUCTIVITY (AIR EXCHANGE), м³/H | 105 |
ROTATION FREQUENCY, RPM | 2500 |
INSTALLATION DIAMETER (MM) | 100 |
NOISE LEVEL, DB | 32 |
PROTECTION CLASS (IP) | IPX4 |
ATTRIBUTES | ball bearing with NSK/SKF |
ADDITIONAL FEATURES | standard |
FAN TYPE | axial |
FRONT PANEL MATERIAL | ABS plastic |
BODY MATERIAL | ABS plastic |
COLOR | white |
